Ürün Detayları

Stack press is a roll-to-roll wide web flexible packaging printer. This printer utilizes Flexo and Stack technology which ensures quality and maximum production speed. This printer allows you to print on substrates such as: paper, plastic films.

Product Introduction

Stack press is a roll-to-roll wide web flexible packaging printer. This printer utilizes Flexo and Stack technology which ensures quality and maximum production speed. This printer allows you to print on substrates such as: paper, plastic films.

Parameter

TECHNICAL SPECIFICATIONS

Model

CH4-600H

CH4-800H

CH4-1000H

CH4-1200H

Max. Web Width

650mm

850mm

1050mm

1250mm

Max. Printing Width

600mm

800mm

1000mm

1200mm

Max. Machine Speed

120m/min

Printing Speed

100m/min

Max. Unwind/Rewind Dia.

φ800mm

Drive Type

Gear drive

Plate thickness

Photopolymer plate 1.7mm or 1.14mm (or to be specified)

Ink

Water base ink or solvent ink

Printing length (repeat)

300mm-1000mm

Range Of Substrates

LDPE; LLDPE; HDPE; BOPP, CPP, PET; Nylon, PAPER, NONWOVEN

Electrical supply

Voltage 380V. 50 HZ.3PH or to be specified

Machine Features

1. Adaptable web printing press: The flexo printing press is highly versatile and can be quickly adapted for various web widths and substrates. It uses anilox rollers to accurately control the volume of ink placed on the paper or substrate.

2. Flexible job scheduling: The flexo printing press can accommodate many different job schedules and is capable of setting up for any job quickly and getting to work immediately. This makes it ideal for frequent job changes and production runs requiring higher output levels.

3. Exceptional print quality: The stack press process boasts razor sharp, high resolution imagery and consistent quality across all jobs of any size or complexity. This makes it a great choice for specialty jobs or jobs requiring exact color matching and precise registration.

4. Low cost and environmental friendliness: One of the major advantages of Stack Flexo Printing Machine is its affordability. It uses fewer chemicals and lower energy cost than other printing processes, making it a more sustainable and cost-effective solution for any business.
