Kraft paper printing machine It can print on almost any type of substrate including plastic, film, paper. Widely used for printing non-porous substrates required for various food packaging. It's also great for printing large
Product Introduction
Kraft paper printing machine which utilizes a flexographic letterpress that can be adhered to the printing cylinder. It's basically an updated version of letterpress. It is more versatile than letterpress because it can print on almost any type of substrate, including plastic, film, paper. Widely used for printing non-porous substrates required for various types of food packaging. It is also great for printing large areas of solid color.
areas of solid color.
Parameter
TECHNICAL SPECIFICATIONS | ||||
Model | CH4-600H | CH4-800H | CH4-1000H | CH4-1200H |
Max. Web Width | 650mm | 850mm | 1050mm | 1250mm |
Max. Printing Width | 600mm | 800mm | 1000mm | 1200mm |
Max. Machine Speed | 120m/min | |||
Printing Speed | 100m/min | |||
Max. Unwind/Rewind Dia. | φ800mm | |||
Drive Type | Gear drive | |||
Plate thickness | Photopolymer plate 1.7mm or 1.14mm (or to be specified) | |||
Ink | Water base ink or solvent ink | |||
Printing length (repeat) | 300mm-1000mm | |||
Range Of Substrates | LDPE; LLDPE; HDPE; BOPP, CPP, PET; Nylon, PAPER, NONWOVEN | |||
Electrical supply | Voltage 380V. 50 HZ.3PH or to be specified | |||
Machine Features
1. Kraft paper printing machine adopts non-toxic,solvent-based ink or uv ink Inherit.
2. Can adapt to a variety of absorbent and non-absorbent printing media;
3. The use of rubber plate or photosensitive resin plate has a strong printing resistance;
4. There are many printing color groups, which can print 10 colors and more than 10 colors;
5. The benefit of short-run live printing is relatively high;
6. Flexographic printing adopts light pressure printing operation, which can be quickly replaced, and the pre-press preparation is simple.
