MING JILEE - P.P Blown Film (Tubular) Extrusion Line ​(Single Side Winder)
MING JILEE - P.P Blown Film (Tubular) Extrusion Line ​(Single Side Winder)
  • MING JILEE - P.P Blown Film (Tubular)  Extrusion Line ​(Single Side Winder)
  • Ürün Açıklaması
  • Foto Galeri
  • Dosyalar
  • Ürün Videosu
  • TEKLİF AL

Extruding speed is control by inverter

Screw and barrel made of special steel with nitrating treatment, grinding, and hard chrome plating, which durable for long time rotation.

Rotary die which is processed by hard chrome plating. The water ring is made by Aluminum.

Serial number
MGPP-75
MGPP-65
MGPP-55
MGPP-45




Model MGPP-45 MGPP-55 MGPP-65 MGPP-75
Applicable resin P.P. granules
Single layer film thickness 0.025 - 0.12 mm
Lay flat film width 100 - 400 mm 150 - 550 mm 200 - 700 mm 550 - 1000 mm
Output 10 - 35 kg/hr 20 - 50 kg/hr 20 - 60 kg/hr 20 - 80 kg/hr
Machine dimension 4,500 (L) × 2,000 (W) × 4,300 (H) mm 4,500 (L) × 2,000 (W) × 4,300 (H) mm 6,360 (L) × 2,100 (W) × 4,700 (H) mm 7,600 (L) × 2,300 (W) × 5,000 (H) mm
Net weight
Required power
Optional equipment (1) 5TON chiller : 1
(2) 200 KG mixer with drier : 1
(3) Hydraulic Cylinder : 1
(4) Corona treatment : 1
(5) Double side embossing station : 1
(6) Double side winding device : 1
Remarks As we continuously keep working on research and improvement, we preserve the right to change all of the specifications, design and characteristics on this catalogue without notice.
