Stand of extruding unit can be movable forward and backward which will increase convenience on controlling.

Screw is special mixing function and hi-plasticizing capability design, it incorporates with European imported static mixer to ensure melting of resins, homogeneous color and increase on extruding output.

T-die is special double throttling design to enable adjustment for sheet thickness to be more accurate.

Temperature control uses SCR system, tolerance of temperature for that is±1℃, this may precisely control plasticizing processes, sheet thickness, flatness and neatness.

Embossing station is operated lifted up and pulled down freely. During operation, this will provide more choices for both thick sheet and thin sheet and to upgrade product quality.

The water flow design of embossing is two loop cooling. The temp setting is control by high quality device to make sure the water supplying is stable.

Winding used high class torque motor, it incorporates with automatic tension controller to enable operator to adjust speed. If it incorporates with slitting device, operator may set up required product width freely. The machine equipped with automatic meter counter to the total length of finished roll.

Electric control box: it completely uses high class and qualified accessories and it is of save space design, operation for that is simple and convenient.



Model MGB-CPP-Serial
Applicable resin P.P.
Effective width 1,100 or 1,200 or 1,450 or 1,650 mm
Thickness range 0.03 - 0.25 mm
Output 60 - 250 kg/hr
Required power 160 kw
Actual power consumption 85 kw
Optional equipment (1) 20 ton chiller : 1
(2) 300 kg mixer with drier system : 1
(3) Auto. Dosing blender : 1
(4) 56/56 gear pump : 1
(5) Twin shaft non-stop screen changer : 1
(6) In-line sheet cutting device : 1
(7) Corona treatment : 1
(8) LF1-1500 thickness scanner : 1
(9) Embossing cylinder : 1 pc (depend on pattern)
Remarks As we continuously keep working on research and improvement, we preserve the right to change all of the specifications, design and characteristics on this catalogue without notice.
